1U - 3U PLATFORM
Looking to break into space? Whether it’s your first mission or a bold tech demo, our 1U–3U CubeSat platforms are your ticket to orbit. With extensive flight heritage, quick turnaround times, and proven reliability, Spacemanic gives you the tools to test, demonstrate, and explore—without waiting years.
Small satellites. Big possibilities. Let’s launch.
From 110k €
SPECIFICATIONS
| 1U | 2U | 3U | |
|---|---|---|---|
| Payload Volume (max) | 0.5U | 1.5U | 2U |
| Payload Mass (max) | 1 kg | 2.5 kg | 4 kg |
| Available Power per PSU Channel (max) | 23 Wh | 48 Wh | 48 Wh |
| Power Output | 3.3 V 5 V |
3.3 V 5 V 12 V |
3.3 V 5 V 12 V |
| Communication (Options) | UHF, VHF | UHF, VHF S-Band L-Band |
UHF, VHF S-Band L-Band |
| Data Interface (CSP v1) | I2C RS-485 CAN |
I2C RS-485 CAN |
I2C RS-485 CAN |
Payload Volume (max)
1U
0.5U
2U
1.5U
3U
2U
Payload Mass (max)
1U
1 kg
2U
2.5 kg
3U
4 kg
Available Power per PSU Channel (max)
1U
23 Wh
2U
48 Wh
3U
48 Wh
Power Output
1U
3.3 V
5 V
5 V
2U
3.3 V
5 V
12 V
5 V
12 V
3U
3.3 V
5 V
12 V
5 V
12 V
Communication (Options)
1U
UHF, VHF
2U
UHF, VHF
S-Band
L-Band
S-Band
L-Band
3U
UHF, VHF
S-Band
L-Band
S-Band
L-Band
Data Interface (CSPv1)
1U
I2C
RS-485
CAN
RS-485
CAN
2U
I2C
RS-485
CAN
RS-485
CAN
3U
I2C
RS-485
CAN
RS-485
CAN
