Flight Heritage
ITAR Free
Eddie OBC
A flight-proven reliable on-board computer designed for satellite CDHS and payload processing in small satellite missions.
Compact. Robust. Ready to fly.
3 600 €
Order Includes
- Module + Shielding
- CAD Model
- Documentation
- Example Source Code
- 1 Engineering Hours
- Shipping & Packaging
Lead Times
12 weeks (HW)
6 months (HW+SW)
Customization
In-house developed hardware and software allows for wide range of customisation. Contact us to learn more.
SPECIFICATIONS
| Operating Temperature | -40°C to +85°C |
| Dimensions | 67 x 42 x 7.5 mm |
| Power Supply | 3.3 V 5 V (CAN) |
| Mass | 25 g |
| Power Consumption | 60 mW average 100 mW peak |
| Operating System | FreeRTOS based |
| On-Board Sensors | Gyro, accelerometer, magnetometer, temperature |
| Microcontroller | MSP430 |
| Clock Speeds |
32.768 kHz (low power mode) 16 MHz (standard mode) |
| Memory | 6x1 MiB external FRAM for data storage |
| Interfaces (CSP v1) |
1x I2C & 1x isolated I2C 1x RS485 1x UART 1x CAN 1x SPI 3x PWM 8x GPIO (4x ADC: 12-bit, 3.3V range) |
EXAMPLE MOUNTING
